This 4MP IP Camera features a large 1/1.8-inch CMOS sensor and delivers a maximum resolution of 2560 × 1440 at up to 25fps. With a 2.8mm fixed F1.0 lens and a wide 107.6° horizontal field of view, the camera is designed to provide detailed and wide-area surveillance coverage.
The camera supports 4MP resolution (2560 × 1440) at up to 25fps, along with 3MP and 1080P at up to 30fps. The 2.8mm F1.0 fixed lens provides a 107.6° horizontal, 58.4° vertical, and 126.4° diagonal field of view.
The camera offers a minimum color illumination of just 0.0003 Lux at F1.0 with AGC ON, supporting surveillance in very low-light environments.
With 120dB WDR, the camera helps balance bright and dark areas within challenging lighting conditions. Additional image enhancement features include 2D/3D DNR, Smart Illumination, HLC, BLC, and Digital Defog.
The camera also supports multiple white-balance modes and flexible image flip options for different installation requirements.
The camera features supplemental warm light with an illumination distance of up to 30 meters (98.4 ft). The warm light can be controlled automatically or manually according to the surveillance environment.
For flexible video transmission, the camera supports Ultra 265, H.265, H.264, and MJPEG video compression. H.264 supports Baseline, Main, and High profiles.
The camera provides dual video streams, with video bitrates ranging from 128Kbps to 6144Kbps. It also supports U-code, up to 4 OSDs, up to 4 privacy mask areas, and ROI.
The camera supports Motion Detection, Ultra Motion Detection, Tampering Alarm, and Audio Detection for event monitoring.
It also provides security functions including watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, and HTTP authentication.
A built-in microphone is supported for audio capture. The camera supports G.711U and G.711A audio compression at 64Kbps.
Two-way audio is not supported, and there is no built-in speaker.
The camera supports MicroSD storage up to 512GB for edge recording. It also supports ANR (Automatic Network Replenishment) and NAS (NFS) for network storage applications.
The camera supports ONVIF Profile S, Profile G, and Profile T, along with API and SDK for integration with compatible surveillance systems.
Network connectivity is provided through 1 × RJ45 10/100M Base-TX Ethernet. The camera supports up to 32 users with three user levels: administrator, common user, and operator.
The camera features IP67 protection according to IEC 60529, providing protection against dust and water ingress.
Its 3-axis adjustment includes 0°–360° pan, 0°–75° tilt, and 0°–360° rotation, allowing flexible positioning during installation.
With the 2.8mm lens, the camera provides the following DORI distances:
Detect: 43.5m
Observe: 17.4m
Recognize: 8.7m
Identify: 4.3m
4MP IP Camera
1/1.8" CMOS sensor
2560 × 1440 @ up to 25fps
2.8mm fixed F1.0 lens
107.6° horizontal field of view
0.0003 Lux minimum color illumination
120dB WDR
30m warm-light illumination
Auto/manual warm-light control
Ultra 265 / H.265 / H.264 / MJPEG
Dual video streams
2D/3D DNR
Smart Illumination
HLC, BLC & Digital Defog
ROI support
Up to 4 OSDs
Up to 4 privacy mask areas
Motion & Ultra Motion Detection
Tampering & Audio Detection
Built-in microphone
MicroSD up to 512GB
ANR & NAS (NFS)
ONVIF Profile S/G/T
API & SDK support
1 × RJ45 10/100M Ethernet
Up to 32 users
IP67 protection
3-axis adjustment
43.5m DORI detection distance
Overall, this 4MP IP Camera combines a 1/1.8-inch CMOS sensor, F1.0 2.8mm lens, 120dB WDR, 0.0003 Lux low-light performance, 30m warm-light illumination, advanced video compression, built-in microphone, 512GB MicroSD support, ONVIF integration, and IP67 protection for dependable network surveillance.
