EZVIZ CB3 2MP Battery Wi-Fi Security Camera with 15m Night Vision
2.8mm F2.0 Lens, 1080p Resolution, 3D DNR & Smart Human Motion Detection
5200mAh Battery, Two-Way Talk, 256GB microSD & EZVIZ CloudPlay Support
| Camera | |
| Image Sensor | 1/2.9” 2-Megapixel Progressive Scan CMOS Sensor |
|---|---|
| Minimum Illumination | 0.01 Lux @(F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed | Self-Adaptive Shutter |
| Lens | 2.8mm @ F2.0 |
| Viewing Angle | 128° Diagonal, 108° Horizontal, 56° Vertical |
| Day & Night | IR-Cut Filter with Auto-Switching |
| DNR | 3D DNR |
| Night Vision | IR Distance up to 15m, Color Night Vision Distance up to 15m |
| Video & Audio | |
| Maximum Resolution | 1080p / 2MP, 1920 × 1080 |
| Frame Rate | Max. 15fps; Self-Adaptive during Network Transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Full HD, Hi-Def, Standard; Adaptive Bit Rate |
| Audio Bit Rate | Self-Adaptive |
| Maximum Bitrate | 1 Mbps |
| Network | |
| Wi-Fi Standard | IEEE 802.11b/g/n |
| Frequency Range | 2.4GHz – 2.4835GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps |
| Wi-Fi Pairing | AP Pairing |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Minimum Network Requirement | 2Mbps |
| Function | |
| Smart Alarm | Smart Human Motion Detection |
| Two-Way Talk | Supports |
| General Function | Anti-Flicker, Heartbeat, Password Protection, Watermark |
| Storage | |
| Local Storage | Supports microSD Card up to 256GB |
| Cloud Storage | Supports EZVIZ CloudPlay Storage; Subscription Required |
| General | |
| Operating Conditions | -20°C to 50°C (-4°F to 122°F), Humidity 95% or Less (Non-Condensing) |
| IP Grade | Weatherproof Design |
| Power Supply | DC 5V / 2A (Purchased Separately) |
| Battery Capacity | 5200mAh |
| Power Consumption | Max. 10W |
| Product Dimensions | 105.9 × 62.8 × 62.8mm |
| Packaging Dimensions | 103 × 103 × 186mm |
| Weight | 480g |
| In the Box | |
| Camera | CB3 Camera |
| Screw Base | |
| USB Cable | |
| Mounting Plate | |
| Drill Template | |
| Screw Kit | |
| Regulatory Information | |
| Quick Start Guide | |
| Certifications | |
| Certifications | CE / FCC / UKCA / WEEE / RoSH / REACH |
The EZVIZ CS-CB3 (1080P) is a 2MP smart security camera designed for reliable monitoring with clear Full HD 1920 × 1080 video. It features a 1/2.9-inch Progressive Scan CMOS sensor and a 2.8mm F2.0 lens with a wide 128° diagonal viewing angle, providing broad coverage for different monitoring areas.
The camera supports both IR and color night vision up to 15 meters, along with an IR-Cut filter with automatic switching for day and night operation. With 3D DNR, self-adaptive shutter, H.265/H.264 video compression, and adaptive bitrate, the CS-CB3 is designed to provide stable video performance under varying network conditions.
For smart monitoring, the camera supports Smart Human Motion Detection and two-way talk. It also includes anti-flicker, heartbeat, password protection, and watermark functions. Wireless connectivity is provided through 2.4GHz Wi-Fi with AP pairing and EZVIZ Cloud proprietary protocol support.
The CS-CB3 supports microSD cards up to 256GB and EZVIZ CloudPlay storage with a subscription. Its 5200mAh battery, weatherproof design, compact dimensions, and operating temperature range of -20°C to 50°C make it suitable for flexible security monitoring applications.
