EZVIZ CS-H9c Dual-Lens 5MP + 5MP Pan & Tilt Wi-Fi Camera
2880×1620 Resolution, 350° Pan, 80° Tilt & 30m Night Vision
AI Human & Vehicle Detection, Auto Tracking, Two-Way Talk & 512GB microSD
| Camera | |
| Model | CS-H9c |
|---|---|
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Effective Pixels | 5MP + 5MP |
| Maximum Resolution | 2880 × 1620 |
| Frame Rate | Max. 15fps; self-adaptive during network transmission |
| Pan & Tilt | Pan 350°, Tilt 80° |
| Fix Lens Field of View | 132° Diagonal, 110° Horizontal, 58° Vertical |
| Pan & Tilt Lens Field of View | 64° Diagonal, 56° Horizontal, 29° Vertical |
| Night Vision | Color Night Vision; Black & White Night Vision up to 30m / 98ft |
| Minimum Illumination | 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Video & Audio | |
| Video Compression | H.265 / H.264 |
| Two-way Talk | Supports |
| Reset Button | Yes |
| Storage | MicroSD Card up to 512GB |
| Cloud Storage | Supports EZVIZ CloudPlay Storage |
| Smart Functions | |
| Smart Alarm | AI-Powered Human Shape Detection, AI-Powered Vehicle Shape Detection, Motion Detection |
| Auto Tracking | Supports |
| Customized Alert Area | Supports |
| General Functions | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Network & Connectivity | |
| Wi-Fi | 2.4GHz Wi-Fi |
| Wi-Fi Standard | IEEE 802.11b/g/n |
| Wired Network | RJ45 × 1, 10M/100M Adaptive Ethernet Port |
| Wi-Fi Pairing | AP Pairing |
| Wi-Fi Security | WPA-PSK / WPA2-PSK |
| Cloud Protocol | EZVIZ Cloud Proprietary Protocol |
| Power | |
| Power Supply | DC 12V/1.5A |
| Power Consumption | Max. 12W |
| Physical Specification | |
| Color | White |
| Weather Protection | Weatherproof Design |
| Operating Temperature | -30°C to 50°C |
| Operating Humidity | 95% or less, non-condensing |
| Dimensions | 145 × 116 × 142mm |
| Packaging Dimensions | 150 × 150 × 194mm |
| Net Weight | 668g |
| Package Weight | 960g |
| Certifications | |
| Certifications | CE / UKCA / WEEE / RoHS / REACH |
| Warranty | |
| Warranty | 01 Year |
The EZVIZ CS-H9c is a dual-lens 5MP+5MP PT Wi-Fi camera designed to provide detailed surveillance with two imaging lenses and a maximum resolution of 2880 × 1620. Its dual-lens configuration combines a fixed lens with a Pan & Tilt lens, allowing users to monitor both wider areas and specific points of interest.
The camera supports 350° pan and 80° tilt movement for flexible monitoring. It features Color Night Vision and up to 30-meter black-and-white night vision, while 3D DNR and Digital WDR help improve image quality in challenging lighting conditions. The IR-cut filter also switches automatically between day and night modes.
For intelligent surveillance, the CS-H9c supports AI-powered human shape detection, AI-powered vehicle shape detection, motion detection, auto tracking, and customized alert areas. Two-way talk enables real-time communication through the camera, while H.265/H.264 compression helps provide efficient video transmission and storage.
The camera supports 2.4GHz Wi-Fi and a 10/100M adaptive RJ45 Ethernet connection, along with MicroSD storage up to 512GB and EZVIZ CloudPlay storage. Its weatherproof design, -30°C to 50°C operating temperature range, and DC 12V/1.5A power supply make it suitable for a variety of residential and commercial surveillance applications.
