This 2MP PoE IP Camera is designed for reliable network surveillance with high-quality Full HD video, excellent low-light performance, and advanced image enhancement. It features a 1/2.7" CMOS sensor with a maximum resolution of 2MP, delivering 1920 × 1080 video at up to 30fps.
The camera uses a 4mm fixed lens with an F1.0 aperture, providing an 85.4° horizontal field of view. Its ColorHunter with Wise-ISP technology is designed to deliver improved color performance in low-light environments, while 120dB WDR helps maintain clearer images in scenes with strong differences between bright and dark areas.
With 120dB WDR, the camera can handle challenging lighting conditions more effectively, helping preserve useful details in both brighter and darker areas of the scene. Additional image features include 2D/3D DNR, HLC, BLC, Digital Defog, Smart Illumination, and multiple White Balance modes.
The camera also supports Auto/Manual shutter control from 1 to 1/100000 seconds, providing flexible image adjustment for different surveillance conditions.
The camera features a warm-light supplemental illumination system with up to 30 meters illumination distance. The light can be controlled automatically or manually according to the installation requirements.
Combined with the camera's ColorHunter with Wise-ISP low-illumination characteristics and F1.0 aperture, the system is designed to maintain useful color images in low-light surveillance environments.
The 4mm fixed lens provides:
Horizontal FOV: 85.4°
Vertical FOV: 47.5°
Diagonal FOV: 98.5°
Aperture: F1.0
The camera also supports Pan 0°–360°, Tilt 0°–90°, and Rotate 0°–360° adjustment for flexible installation positioning.
The camera provides the following DORI distances with its 4mm lens:
Detect: Up to 64.3 meters
Observe: Up to 25.7 meters
Recognize: Up to 12.9 meters
Identify: Up to 6.4 meters
These values can help in planning suitable camera placement and surveillance coverage.
The camera supports Ultra 265, H.265, H.264, and MJPEG video compression. The main stream supports 1080P and 720P at up to 30fps, while the sub stream supports resolutions including 720P, D1, 640 × 360, 2CIF, and CIF at up to 30fps.
Video bitrate can be configured from 128 Kbps to 6144 Kbps. The camera also supports U-Code, ROI, OSD up to 4 areas, privacy masking up to 4 areas, and dual video streams.
The camera supports several basic detection functions, including:
Motion Detection
Ultra Motion Detection
Tampering Alarm
Audio Detection
It also includes security functions such as watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, and HTTP authentication.
A built-in microphone is supported for audio capture. The camera supports G.711U and G.711A audio compression with a 64 Kbps audio bitrate and 8 kHz sampling rate.
Two-way audio is not supported, as the supplied specification lists it as N/A.
For edge storage, the camera supports MicroSD cards up to 512GB. It also supports ANR (Automatic Network Replenishment) and NAS storage through NFS, providing additional options for video storage and network recording.
The camera supports both DC 12V ±25% power and IEEE 802.3af PoE, allowing power and network connectivity to be delivered through a compatible Ethernet connection.
For networking, it features 1 × RJ45 10/100M Base-TX Ethernet port and supports a wide range of network protocols including IPv4, IPv6, TCP, UDP, DHCP, PPPoE, RTSP, HTTP, HTTPS, FTP, SMTP, NTP, SNMP, RTMP, SSL/TLS, and QoS.
The camera supports ONVIF Profile S, Profile G, and Profile T, along with API and SDK, making it suitable for integration with compatible surveillance management platforms and third-party systems.
It supports up to 32 users with three user levels: Administrator, Common User, and Operator. Security features include password protection, strong password support, HTTPS encryption, TLS 1.2, and authentication mechanisms for RTSP, HTTP, and ONVIF.
The camera carries an IP67 protection rating according to IEC 60529, providing protection against dust and water ingress for suitable installation environments.
It is constructed using Graphene + Plastic and supports an operating temperature range of -30°C to 60°C, with humidity up to 95% RH (non-condensing).
The camera also provides 4KV surge protection and includes a reset button.
2MP Full HD IP Camera
1/2.7" CMOS sensor
1920 × 1080 resolution at up to 30fps
4mm fixed lens
F1.0 fixed aperture
85.4° horizontal FOV
120dB WDR
ColorHunter with Wise-ISP
Up to 30m warm-light illumination
Smart Illumination
2D/3D DNR
HLC & BLC
Digital Defog
Ultra 265 / H.265 / H.264 / MJPEG
U-Code support
Dual video streams
Motion & Ultra Motion Detection
Tampering & Audio Detection
Built-in microphone
MicroSD support up to 512GB
ANR & NAS (NFS) support
IEEE 802.3af PoE
1 × RJ45 10/100M Ethernet
ONVIF Profile S/G/T
API & SDK support
IP67 protection
4KV surge protection
Maximum power consumption: 2.6W
DORI Detect distance up to 64.3m
This 2MP PoE ColorHunter IP Camera is suitable for applications such as:
Home surveillance
Office security
Retail shops
Commercial premises
Entrance monitoring
Building surveillance
Indoor and suitable outdoor installations
Low-light security monitoring
Network-based CCTV systems
Overall, this 2MP PoE IP Camera with 120dB WDR, F1.0 fixed lens, ColorHunter with Wise-ISP, 30m warm light, built-in microphone, MicroSD support, ONVIF compatibility, and IP67 protection provides a feature-rich solution for Full HD network surveillance and low-light monitoring.
