12MP NVR with AcuSense, AcuSeek, 8-Channel Playback & Dual SATA Storage
This 12MP Network Video Recorder (NVR) is designed for high-resolution IP camera surveillance systems, offering advanced recording, playback, smart search, remote access, and large-capacity storage capabilities. It supports up to 12MP IP cameras, dual SATA interfaces, and advanced smart surveillance technologies including AcuSense, AcuSeek, face detection, and face comparison.
With 80 Mbps incoming bandwidth and 160 Mbps outgoing bandwidth, the NVR provides reliable network performance for IP-based video surveillance. It also supports up to 8-channel synchronous playback, smart search, USB/network backup, and remote monitoring through mobile applications and web browsers.
The NVR supports IP cameras with recording capability for up to 12MP resolution, making it suitable for high-resolution surveillance systems.
It supports H.265+, H.265, H.264+, and H.264 video compression technologies to improve storage efficiency while maintaining recorded video quality.
The NVR features advanced smart surveillance functions, including:
AcuSense human & vehicle classification
AcuSeek fast search
Face detection
Face comparison
Motion Detection 2.0
Line crossing detection
Intrusion detection
Video tampering alarm
Smart alerts
These features help users search and review important surveillance events more efficiently.
For expanded recording storage, the NVR provides 2 SATA interfaces, with each interface supporting up to 10TB HDD capacity.
This provides a maximum supported storage capacity of up to 20TB when both SATA interfaces are populated with 10TB HDDs.
The NVR supports high-resolution display output for live monitoring and playback:
HDMI output up to 4K (3840 × 2160)
VGA output up to 1080P
Live view support
Playback support
Multi-screen display
This allows users to monitor and review surveillance footage on compatible displays.
The NVR supports up to 8-channel synchronous playback, allowing multiple camera recordings to be reviewed simultaneously.
It also supports smart search and backup through USB devices or network connections, making recorded footage easier to locate and export.
The recorder supports different recording modes, including:
Continuous recording
Motion detection recording
Scheduled recording
High-resolution recording
It also supports audio over IP and two-way audio, along with available audio input and output interfaces.
The NVR features 1× RJ-45 10/100/1000 Mbps Ethernet interface and supports up to:
80 Mbps incoming bandwidth
160 Mbps outgoing bandwidth
Network protocols and services include TCP/IP, DHCP, Hik-Connect, DNS, DDNS, and NTP.
The NVR also supports ONVIF-compatible devices, as well as remote access through a mobile app and web browser.
The NVR operates on an Embedded Linux OS and provides a user-friendly GUI with multi-user access support. Its compact design and broad network functionality make it suitable for managing multiple IP cameras from a centralized recorder.
Up to 12MP IP Camera Support
AcuSense Human & Vehicle Classification
AcuSeek Fast Search
Face Detection & Face Comparison
Motion Detection 2.0
Line Crossing & Intrusion Detection
Video Tampering Alarm
Smart Alerts
80 Mbps Incoming Bandwidth
160 Mbps Outgoing Bandwidth
Up to 8-Channel Synchronous Playback
4K HDMI Output (3840 × 2160)
1080P VGA Output
2× SATA Interfaces
Up to 10TB per SATA Interface
Up to 20TB Total Supported HDD Capacity
H.265+ / H.265 / H.264+ / H.264 Compression
2× USB 2.0 Ports
1× RJ-45 10/100/1000 Mbps Ethernet
Audio Input/Output
Audio over IP
Two-Way Audio
USB & Network Backup
Smart Search
ONVIF Device Support
Mobile App & Web Browser Remote Access
Embedded Linux OS
Multi-User Access
1-Year Warranty
| Specification | Details |
|---|---|
| Device Type | Network Video Recorder (NVR) |
| IP Camera Support | Up to 12MP IP Cameras |
| Incoming Bandwidth | Up to 80 Mbps |
| Outgoing Bandwidth | Up to 160 Mbps |
| HDMI Output | Up to 4K (3840 × 2160) |
| VGA Output | Up to 1080P |
| Display Functions | Live View, Playback, Multi-Screen Display |
| Playback | Up to 8-Channel Synchronous Playback |
| Recording Modes | Continuous, Motion Detection, Scheduled |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| HDD Interface | 2× SATA |
| HDD Capacity | Up to 10TB per SATA Interface |
| Maximum Supported Storage | Up to 20TB |
| Network Interface | 1× RJ-45 10/100/1000 Mbps |
| USB Ports | 2× USB 2.0 |
| Audio | Audio Input/Output, Audio over IP |
| Two-Way Audio | Supported |
| Smart Features | AcuSense, AcuSeek, Face Detection & Face Comparison |
| Video Detection | Motion Detection 2.0, Line Crossing, Intrusion Detection |
| Alarm | Video Tampering Alarm, Smart Alerts |
| Network Protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP |
| Device Compatibility | ONVIF Compatible Devices |
| Remote Access | Mobile App & Web Browser |
| Operating System | Embedded Linux |
| GUI | User-Friendly, Multi-User Access |
| Backup | USB Device / Network |
| Warranty | 1 Year |
This 12MP NVR is suitable for IP camera surveillance systems that require high-resolution recording, large storage capacity, advanced event detection, intelligent search, multi-channel playback, and remote access.
Overall, this NVR combines 12MP IP camera support, AcuSense human and vehicle classification, AcuSeek fast search, face detection and comparison, 8-channel synchronous playback, 4K HDMI output, dual SATA storage, Gigabit networking, and advanced motion and intrusion detection in a centralized network video recording solution.
