1080p Smart Video Doorbell with 4.3" Color Screen
2.0mm Ultra-Wide Lens, 155° Viewing Angle & 5m IR Night Vision
4600mAh Rechargeable Battery, Two-Way Calling & 512GB MicroSD
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
|---|---|
| Video Resolution | 1080p |
| Lens | 2.0mm @ F2.2 |
| Viewing Angle | 155° Diagonal Ultra-Wide Angle |
| Night Vision | IR Night Vision up to 5m |
| Motion Detection | PIR Motion Detection |
| Video Technology | H.265 Video Technology |
| Display | |
| Screen | 4.3-inch Color Screen |
| Audio | |
| Two-Way Calling | Supports |
| Microphone | Built-in High-Sensitivity Microphone |
| Speaker | Built-in High-Power Speaker |
| Doorbell | Built-in Electronic Doorbell |
| Connectivity | |
| Wi-Fi Standard | IEEE 802.11b/g/n |
| Frequency Range | 2.4GHz – 2.4835GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Storage | |
| Local Storage | Supports MicroSD Card up to 512GB |
| Cloud Storage | EZVIZ CloudPlay Storage |
| Power | |
| Power Supply | DC 5V (±10%) |
| Power Consumption | Max. 2.2W |
| Battery Capacity | 4,600mAh Rechargeable Lithium Battery |
| Physical Description | |
| Color | Silver / Golden |
| Weight | 302g |
| Screen and Base Dimensions | 115.5 × 85.5 × 24.5mm |
| Peephole Doorbell Dimensions | 71 × 71 × 48.3mm |
| Warranty | |
| Warranty | 1 Year |
The EZVIZ CS-DP2C Smart Video Doorbell is a wire-free peephole doorbell designed to provide clear and convenient visitor monitoring at the entrance of your home. It features a 1/3-inch Progressive Scan CMOS sensor with a 2.0mm F2.2 lens and delivers 1080p video with a 155° ultra-wide diagonal viewing angle for broad doorway coverage.
The doorbell is equipped with PIR motion detection and supports IR night vision up to 5 meters, helping monitor visitors and activity during both daytime and nighttime. Its built-in high-sensitivity microphone and high-power speaker support two-way calling, allowing convenient communication with visitors.
Inside the home, the 4.3-inch color screen provides a convenient way to view visitors and interact with the doorbell. The device uses 2.4GHz Wi-Fi connectivity and supports multiple wireless security standards, while H.265 video technology helps provide efficient video transmission.
The CS-DP2C is powered by a 4,600mAh rechargeable lithium battery and has a built-in electronic doorbell. For recording and storage, it supports MicroSD cards up to 512GB as well as EZVIZ CloudPlay storage. With its compact design, silver/golden color options, and 1-year warranty, it is suitable for modern home entrance security.
