3MP PoE IP Camera with 30m Smart IR Night Vision
2.8mm/4mm Fixed Lens, 112.9° Horizontal Viewing Angle & IP67
PoE, 4KV Surge Protection, 2D/3D DNR & -30°C to 60°C Operation
| Camera | |
| Image Sensor | 1/2.7" 3.0 Megapixel Progressive Scan CMOS |
|---|---|
| Minimum Illumination | Color: 0.01 Lux (F2.0, AGC ON) |
| Minimum Illumination with IR | 0 Lux |
| IR Distance | Smart IR, up to 30m (98ft) |
| Shutter | Auto / Manual, 1/100000s to 1s |
| Material | Metal + Plastic |
| Lens | |
| Lens Type | Fixed-focal |
| Focal Length | 2.8mm / 4.0mm |
| Aperture | F2.0 |
| Lens Mount | M12 |
| Angle of View | 112.9° × 59.1° × 121.2° (H × V × D) |
| IR Control | Auto / Manual |
| IR Wavelength | 850nm |
| Image Flip | Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise |
| Digital Noise Reduction | 2D DNR / 3D DNR |
| Network & Interface | |
| Network Interface | 1 × RJ45 10/100M Base-TX Ethernet |
| Power Interface | Ø5.5mm coaxial power plug |
| PoE | IEEE 802.3af |
| Network Storage | ANR, NAS (NFS) |
| Power | |
| Power Supply | DC 12V ±25%, PoE |
| Maximum Power Consumption | 7.0W |
| Protection & Environment | |
| Water & Dust Protection | IP67 |
| Surge Protection | 4KV |
| Working Temperature | -30°C to 60°C (-22°F to 140°F) |
| Working Humidity | ≤95% RH, non-condensing |
| Defog | Digital Defog |
| Reset Button | N/A |
| Physical Specification | |
| Dimensions | Φ118 × 96mm |
| Weight | 0.30kg |
| Warranty | |
| Warranty | 1 Year |
This 3MP fixed-focal IP camera features a 1/2.7-inch progressive scan CMOS sensor and delivers clear surveillance imaging with a resolution suitable for a wide range of security monitoring applications. With Smart IR technology and up to 30m IR distance, it provides reliable night-time visibility while automatically adjusting infrared illumination according to the scene.
The camera supports 2.8mm and 4.0mm fixed-focal lens options with an M12 lens mount and offers a wide field of view. It also includes Auto/Manual shutter control, 2D/3D Digital Noise Reduction, and multiple image-flip options for flexible installation and monitoring.
For network connectivity, the camera features a 10/100M RJ45 Ethernet interface and supports both DC 12V power and PoE through IEEE 802.3af. Network storage features include ANR and NAS (NFS), while Digital Defog helps improve image visibility in challenging conditions.
Built with a metal and plastic construction, the camera has IP67 water and dust protection and supports operation from -30°C to 60°C. With 4KV surge protection, up to 30m IR range, and PoE connectivity, it is suitable for demanding surveillance installations.
