5MP Wi-Fi PT Camera with 2880×1620 Resolution & 30m Warm Light
3.6mm F1.0 Lens, 345° Pan / 90° Tilt & 120dB WDR
Human & Vehicle Detection, Two-Way Audio & 512GB MicroSD Support
| Camera | |
| Image Sensor | 1/1.8" CMOS |
|---|---|
| Maximum Resolution | 2880 × 1620 |
| Electronic Shutter Speed | 1–1/100,000 s |
| Minimum Illumination | 0.0005 lux @ F1.0 (Color, 30 IRE); 0 lux (Illuminator On) |
| Illumination Distance | 30 m Warm Light |
| Illuminator | 4 Warm Lights |
| Lens | |
| Focal Length | 3.6 mm |
| Maximum Aperture | F1.0 |
| Field of View | H 89.5°; V 51°; D 96° |
| PTZ | |
| Pan/Tilt Range | Pan 0°–345°; Tilt 0°–90° |
| Smart Event | |
| Human Detection | Yes |
| Vehicle Detection | Yes |
| Video | |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264B; H.264M; H.264H; MJPEG (Sub Stream 1) |
| Video Frame Rate | Main Stream: 5MP/3MP/720p @ 1–25/30 fps; Sub Stream 1: 640 × 360/QVGA @ 1–25/30 fps |
| Day/Night | Color/B&W |
| WDR | 120 dB |
| Motion Detection | Yes |
| Image Rotation | 180° |
| Audio | |
| Audio Compression | PCM; G.711A; G.711Mu |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Wi-Fi Standard | IEEE 802.11b/g/n/ax |
| Wi-Fi Frequency | 2.4 GHz |
| Wi-Fi Transmission Rate | 229 Mbps |
| Wi-Fi Pairing | Bluetooth Pairing |
| Maximum Transmission Power | ≤20 dBm @ 2400–2483.5 MHz |
| Interoperability | ONVIF Profile S/G/T; CGI; SDK |
| Storage | Micro SD Card up to 512 GB; FTP |
| Management Software | DMSS; NVR |
| Mobile Client | iOS; Android |
| Function | |
| Abnormal Sound Alarm | Yes |
| Power | |
| Power Supply | 12 VDC, 1 A ±10% |
| Power Consumption | Basic 3 W; Max. 9 W (WDR + Light On + PTZ Operation) |
| Environment | |
| Operating Temperature | –30 °C to +55 °C |
| Operating Humidity | ≤95% |
| Protection | IP66; TVS 2000 V Lightning Proof; Surge Protection; Voltage Transient Protection |
| General | |
| Certification | CE |
| Product Dimensions | 153.5 mm × Φ129.3 mm |
| Net Weight | 0.60 kg |
This 5MP Pan & Tilt Wi-Fi Network Camera features a large 1/1.8" CMOS sensor with 2880 × 1620 resolution, delivering detailed video for surveillance applications. Its 3.6 mm F1.0 fixed lens provides a 89.5° horizontal field of view, while the pan and tilt mechanism offers 0°–345° pan and 0°–90° tilt coverage.
The camera provides up to 30 m warm-light illumination with four warm lights for enhanced night monitoring. It supports 120 dB WDR, motion detection, Color/B&W day and night modes, and 180° image rotation for flexible surveillance.
Smart features include Human Detection and Vehicle Detection, helping identify relevant targets. Built-in microphone and speaker support two-way audio, while Abnormal Sound Alarm provides an additional security function.
For connectivity, the camera supports 2.4 GHz Wi-Fi 6 (802.11ax) along with 10/100 Base-T Ethernet and Bluetooth pairing. Micro SD storage up to 512 GB, FTP, ONVIF, CGI and SDK support provide flexible storage and integration options. IP66 protection, surge protection and TVS 2000 V lightning protection further support reliable installation.
