Netis NC21 AC1200 Dual-Band WiFi Router

## AC1200 Dual-Band WiFi 5 Router with Beamforming, High-Power FEM & Multiple Modes

The AC1200 Dual-Band WiFi 5 Router is a versatile and high-performance networking solution designed for homes, apartments, offices, and small businesses that require stable wireless connectivity across multiple devices. With combined wireless speeds of up to 1200Mbps, 4 fixed high-performance antennas, Beamforming technology, and High-Power FEM, this router delivers reliable WiFi coverage and efficient network performance for everyday browsing, HD streaming, online gaming, video conferencing, and smart home connectivity.

### AC1200 Dual-Band WiFi Performance

The router supports dual-band WiFi 5 connectivity with:

- 5GHz: Up to 867Mbps
- 2.4GHz: Up to 300Mbps
- AC1200 wireless performance
- IEEE 802.11ac/n on 5GHz
- IEEE 802.11b/g/n on 2.4GHz

The 5GHz band is ideal for high-speed applications such as streaming, gaming, and large file transfers, while the 2.4GHz band provides broader compatibility and better penetration through walls.

### 4 High-Performance Antennas

Equipped with 4 fixed high-performance antennas, the router forms a signal-boosting array designed to distribute wireless signals across multiple directions. It is suitable for coverage in typical 3-bedroom houses and other medium-sized indoor environments.

Actual WiFi coverage depends on walls, interference, building structure, connected devices, and router placement.

### Beamforming & High-Power FEM

The router features **Beamforming technology**, which concentrates wireless signal strength toward connected clients to help improve signal quality, range, and connection stability.

The **High-Power FEM (Front-End Module)** increases transmission performance to strengthen wireless signal coverage and improve connectivity across the network.

### Multiple Working Modes

This router provides several operating modes for flexible network deployment:

- AP Router Mode
- AP Mode
- WISP Mode
- Client Mode
- Repeater Mode

These modes allow the router to be configured according to different networking requirements, including extending an existing WiFi network or creating a dedicated wireless access point.

### Fast Wired Connectivity

The router features:

- 1× Fast WAN Port
- 3× Fast LAN Ports

These ports can be used to connect computers, smart TVs, gaming consoles, NVRs, printers, and other Ethernet-enabled devices.

### Flexible Internet Connection Support

The router supports multiple WAN connection types, including:

- DHCP
- Static IP
- PPPoE
- L2TP
- PPTP

It also supports IPv4 and IPv6 protocols for flexible network configuration.

### Advanced Network Management

The router provides a wide range of networking functions, including:

- QoS by Device
- Bandwidth Control
- Multiple SSID
- Virtual Server
- DMZ
- UPnP
- IPTV Bridge
- VLAN Tag
- DHCP Address Reservation
- DHCP Client List
- IP Filtering
- MAC Filtering
- Domain Filtering
- IPv6 Filtering
- DDNS
- Static Routing
- Remote Access
- Backup & Restore

These features make the router suitable for users who need greater control over their home or office network.

### VPN & Network Compatibility

The router supports multiple VPN pass-through functions, including:

- PPTP Pass-through
- L2TP Pass-through
- IPSEC Pass-through
- SIP Pass-through

It also supports IGMP Proxy and IGMP Snooping for compatible IPTV and multicast networking applications.

### Key Features

- AC1200 Dual-Band WiFi 5 Router
- 5GHz speed up to 867Mbps
- 2.4GHz speed up to 300Mbps
- 4× Fixed High-Performance Antennas
- Beamforming technology
- High-Power FEM
- WiFi coverage suitable for 3-bedroom houses*
- AP Router Mode
- AP Mode
- WISP Mode
- Client Mode
- Repeater Mode
- 1× Fast WAN Port
- 3× Fast LAN Ports
- IEEE 802.11ac/n 5GHz
- IEEE 802.11b/g/n 2.4GHz
- WEP, WPA-PSK & WPA2-PSK security
- DHCP, Static IP, PPPoE, L2TP & PPTP
- QoS by Device
- Multiple SSID
- IPTV & VLAN support
- IPv4 & IPv6
- VPN Pass-through
- DDNS support
- FOTA support
- TR-069 support
- Wake-on-LAN (WOL)
- Static Routing
- Remote Access
- 1GHz CPU
- RTL8197FH-VG5 + RTL8812FR chipset
- 128MB RAM / 8MB Flash
- 12V/1A Power Supply
- White Color
- 228 × 134 × 188mm Dimensions
- 1-Year Manufacturer Warranty

### Ideal Applications

This AC1200 Dual-Band Router is suitable for:

- 3-bedroom homes
- Apartments
- Home WiFi networks
- Small offices
- Small businesses
- Internet sharing
- HD video streaming
- Online gaming
- Video conferencing
- Smart home devices
- CCTV/NVR networking
- WiFi range extension
- IPTV connectivity

### Why Choose This AC1200 WiFi Router?

The AC1200 Dual-Band WiFi 5 Router offers an excellent combination of **fast dual-band wireless performance, 4 high-performance antennas, Beamforming, High-Power FEM, multiple operating modes, and advanced network management features**. With support for Router, AP, WISP, Client, and Repeater modes, it provides the flexibility needed for different home and office networking environments.

### Physical Specifications

- Dimension: 228 × 134 × 188mm
- Color: White
- Processor: 1GHz CPU
- RAM: 128MB
- Flash: 8MB
- Power Supply: 12V/1A
- Warranty: 1 Year Manufacturer Warranty

*Actual WiFi coverage varies depending on building structure, walls, interference, router placement, and connected devices.
