The 32-Channel Network Video Recorder (NVR) is a professional surveillance recording solution designed to manage large-scale IP camera systems. With support for 32 IP camera channels and recording resolutions up to 12MP, it provides a powerful platform for high-resolution video surveillance.
This NVR supports up to 32 IP camera channels, making it suitable for larger CCTV installations requiring multiple network cameras. It supports a wide range of recording resolutions, from standard resolutions up to 12MP.
Supported recording resolutions include:
12MP
8MP
6MP
5MP
4MP
3MP
1080p
UXGA
720p
VGA
4CIF
DCIF
2CIF
CIF
QCIF
The NVR supports 16-channel synchronous playback, allowing multiple recorded camera channels to be reviewed simultaneously for efficient surveillance monitoring and investigation.
For surveillance investigation, the NVR provides dedicated face-related search functions, including:
Face picture comparison
Human face capture
Face picture search
These functions help users locate and review relevant face images and recorded surveillance footage more efficiently.
The recorder features 1-channel RCA audio connectivity for two-way talk, with a linear audio specification of 1 kΩ.
The NVR supports alarm input, allowing compatible alarm devices to be integrated into the surveillance system.
The recorder includes 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface, providing network connectivity for IP surveillance and data communication.
The NVR supports up to 10TB capacity for each HDD, providing substantial storage capacity for high-resolution surveillance recordings.
The NVR includes two USB ports for compatible devices:
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 2.0
The recorder operates on a 12V DC, 3.3A power supply and has a power consumption of less than 15W without HDD.
Its compact construction measures 385 × 315 × 52mm, with a net weight of less than 1kg.
32-channel IP camera input
Up to 12MP recording resolution
12MP / 8MP / 6MP / 5MP / 4MP / 3MP
1080p / UXGA / 720p / VGA
4CIF / DCIF / 2CIF / CIF / QCIF
16-channel synchronous playback
Face picture comparison
Human face capture
Face picture search
1-channel RCA two-way talk
Alarm input support
1 × RJ-45 10/100/1000 Mbps Ethernet
Up to 10TB capacity for each HDD
2 × USB 2.0
12V DC, 3.3A power supply
Power consumption <15W without HDD
Dimensions: 385 × 315 × 52mm
Net weight: <1kg
1-year manufacturing warranty
This 32-Channel 12MP NVR is suitable for larger IP surveillance systems in offices, commercial buildings, warehouses, institutions, retail environments, and other professional security installations where high-resolution recording, multi-channel playback, face search, and large-capacity HDD support are required.
