2MP Full HD Wi-Fi Battery Security Camera with 10m IR
4mm F1.6 Lens, Smart Human Motion Detection & Two-Way Talk
512GB MicroSD, EZVIZ CloudPlay & 2000mAh Battery
| Camera | |
| Image Sensor | 1/2.8" 2-Megapixel Progressive Scan CMOS |
|---|---|
| Effective Pixels | 2MP |
| Maximum Resolution | 1920 × 1080 |
| Frame Rate | 15fps, Self-Adaptive During Network Transmission |
| Lens | 4mm @ F1.6 |
| Lens Mount | M12 |
| Field of View | 100° Diagonal, 85° Vertical, 46° Horizontal |
| Minimum Illumination | 0.1 Lux |
| Video Compression | H.265 / H.264 |
| Bit Rate | Full HD / Hi-Def / Standard |
| Maximum Bitrate | 1 Mbps |
| DNR | 3D DNR |
| Audio & Smart Features | |
| Audio | Two-Way Talk |
| Smart Alarm | Smart Human Motion Detection |
| Button | Reset Button |
| Storage | |
| Local Storage | MicroSD Card |
| Maximum MicroSD Capacity | Up to 512GB |
| Cloud Storage | EZVIZ CloudPlay, Subscription Required |
| Network & Connectivity | |
| Wireless Network | IEEE 802.11b/g/n |
| Wi-Fi Frequency | 2.4GHz–2.4835GHz |
| Power | |
| Power Supply | DC 5V / 1A |
| Battery Capacity | 2000mAh |
| Physical Specification | |
| Dimension | 50.5 × 39.1 × 39.1 mm |
| Weight | 86.8g |
| Package Weight | 273g |
| Operating Temperature | -10°C to 45°C |
| Operating Humidity | 95% or Less, Non-Condensing |
| Certifications | |
| Certifications | CE / WEEE / RoHS / REACH / UL |
| Warranty | |
| Warranty | 1 Year |
The EZVIZ CS-CB2 2MP Wi-Fi Smart Home Battery Security Camera is designed for flexible security monitoring with a 1/2.8" 2MP Progressive Scan CMOS sensor. It supports a maximum resolution of 1920 × 1080 and up to 15fps, delivering clear Full HD video for everyday surveillance applications.
The camera features a 4mm F1.6 lens with an M12 lens mount and a wide field of view of 100° diagonal, 85° vertical, and 46° horizontal. With 3D DNR, the camera helps reduce image noise for clearer video, while H.265/H.264 compression and adaptive bitrate support efficient video transmission.
For intelligent monitoring, the EZVIZ CS-CB2 supports smart human motion detection. Two-way talk enables communication through the camera, while the built-in reset button provides convenient device management. The camera also supports MicroSD cards up to 512GB as well as EZVIZ CloudPlay storage with a subscription.
The camera supports 2.4GHz Wi-Fi through IEEE 802.11b/g/n and operates with a DC 5V/1A power supply. Its 2000mAh battery provides added flexibility, while the compact 50.5 × 39.1 × 39.1 mm design and 86.8g weight make it convenient for different monitoring applications. The camera operates from -10°C to 45°C with up to 95% non-condensing humidity and comes with a 1-year warranty.
