5MP Smart Dual Light HDCVI Bullet Camera with 40m IR & Warm Light
2880×1620 Resolution, 3.6mm F1.6 Fixed Lens & CVI/TVI/AHD/CVBS Support
Built-in Mic, Super Adapt, 2D NR & IP67 Protection
| General | |
| Casing | Metal front cover + plastic rear barrel + metal bracket |
|---|---|
| Dimensions | 198.4 × 80.2 × 76.2mm |
| Weight | 0.3kg |
| Pan/Tilt/Rotation | Pan 0°–360° / Tilt 0°–90° / Rotation 0°–360° |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -40°C to +60°C |
| Power Supply | 12V DC ±30% |
| Power Consumption | Max. 4.5W (12V DC, WLED On) |
| Camera | |
| Image Sensor | 5MP CMOS |
| Effective Pixels | 2880(H) × 1620(V) |
| Scanning System | Progressive |
| Electronic Shutter | PAL: 1/25s–1/100000s; NTSC: 1/30s–1/100000s |
| Minimum Illumination | 0.05 lux @ F1.6 (Color, 30 IRE); 0.005 lux @ F1.6 (B/W, 30 IRE); 0 lux (Illuminator On) |
| S/N Ratio | More than 65dB |
| IR Distance | 40m |
| Warm Light Distance | 40m |
| IR On/Off Control | Auto / Manual |
| Illuminators | 2 Warm Light + 2 IR Light |
| Lens | |
| Lens Type | Fixed-Focal |
| Mount Type | M12 |
| Focal Length | 3.6mm |
| Maximum Aperture | F1.6 |
| Angle of View | 3.6mm — H: 92° / V: 48° / D: 109° |
| Additional FOV | 2.8mm — H: 106° / V: 56° / D: 125° |
| Close Focus Distance | 1.3m (3.6mm) |
| Video | |
| Resolution | 5MP (2880 × 1620); 4MP (2560 × 1440); 1080p (1920 × 1080); 960H |
| CVI | PAL 5MP@25fps, 4MP@25fps, 1080p@25fps; NTSC 5MP@25fps, 4MP@30fps, 1080p@30fps |
| AHD | PAL 4MP@25fps; NTSC 4MP@30fps |
| TVI | PAL 4MP@25fps; NTSC 4MP@30fps |
| CVBS | PAL/NTSC 960H |
| Video Output | CVI / TVI / AHD / CVBS via 1 × BNC |
| Day/Night | Auto (ICR) / Color / B/W |
| BLC Mode | BLC / HLC / DWDR |
| Gain Control | Auto / Manual |
| Noise Reduction | 2D NR |
| Audio & Interface | |
| Audio | Built-in Microphone |
| Video Interface | 1 × BNC |
| Signal Formats | CVI / TVI / AHD / CVBS |
| Special Features | |
| Smart Dual Light | Yes |
| Illumination Distance | Up to 40m |
| Super Adapt | Supported |
| Built-in MIC | Yes |
| Ingress Protection | IP67 |
| Warranty | |
| Warranty | 1 Year |
This 5MP fixed-focal camera delivers detailed surveillance video with a 5MP CMOS sensor and a maximum resolution of 2880 × 1620. Progressive scanning and multiple resolution options including 4MP, 1080p and 960H provide flexible video monitoring and recording.
The camera features Smart Dual Light technology with up to 40m IR and warm-light illumination. It supports Auto/Manual IR control and provides clear visibility in different lighting conditions. The 3.6mm M12 fixed-focal lens offers a 92° horizontal, 48° vertical and 109° diagonal field of view.
For image enhancement, the camera supports Super Adapt, BLC, HLC, DWDR, Auto/Manual gain control and 2D noise reduction. It also includes a built-in microphone and supports CVI, TVI, AHD and CVBS video formats through a single BNC port.
The camera operates on 12V DC ±30% with a maximum power consumption of 4.5W when the WLED is on. Its metal front cover, plastic rear barrel and metal bracket construction, IP67 protection and operating temperature range of -40°C to +60°C provide reliable performance for compatible surveillance installations. A 1-year warranty is included.
