Dahua DH-HAC-HDW1200TQP-IL-T 2MP Smart Dual Light HDCVI Eyeball Dome Camera
1920×1080 Full HD, 2.8mm/3.6mm Fixed-Focal Lens & 25m IR with Warm Light
Built-in Mic & Speaker, Two-Way Talk, DWDR, 3D NR & Audio over Coax
| General | |
| Brand | Dahua |
|---|---|
| Model | DH-HAC-HDW1200TQP-IL-T |
| Camera Type | HDCVI Eyeball Dome Camera |
| Camera | |
| Image Sensor | 2MP CMOS |
| Maximum Resolution | 1920 × 1080 |
| Minimum Illumination | 0.01 Lux @ F2.0 Color; 0.001 Lux @ F2.0 B/W; 0 Lux with Illuminator On |
| Signal System | CVI / TVI / AHD / CVBS |
| Shutter Speed | PAL: 1/25s to 1/100,000s; NTSC: 1/30s to 1/100,000s |
| Day/Night | Auto ICR / Color / B/W |
| WDR | DWDR |
| Image Enhancement | BLC, HLC, DWDR, 3D Noise Reduction |
| White Balance | Auto |
| AGC | Auto / Manual Gain Control |
| Image Control | Smart IR & Warm Light, Warm Light Mode, IR Mode |
| Smart IR & WL | Supported via CVI / TVI |
| Mirror | Supported, controlled through XVR |
| Lens | |
| Lens Type | Fixed-Focal Lens |
| Lens Options | 2.8mm / 3.6mm |
| Aperture | F2.0 |
| Lens Mount | M12 |
| Field of View (2.8mm) | H: 111.3°, V: 60.8°, D: 134.2° |
| Field of View (3.6mm) | H: 89°, V: 48.2°, D: 109.1° |
| Illumination | |
| Light Type | Multi-Core Light, IR + Warm Light |
| IR Distance | Up to 25m |
| Illumination Modes | Smart IR & Warm Light, Warm Light Mode, IR Mode |
| Pan & Tilt | |
| Pan Range | 0° to 355° |
| Tilt Range | 15° to 85° |
| Presets | 80 Presets |
| Video | |
| Video Output | 1 × BNC, Switchable CVI / TVI / AHD / CVBS |
| Max Frame Rate (CVI / AHD / TVI) | 1080p @ 25fps PAL; 1080p @ 30fps NTSC |
| CVBS | 960H PAL / NTSC |
| Resolution Support | 1080p 1920 × 1080; 960H 960 × 576 / 960 × 480 |
| Video Interface | 1 × BNC Video Output |
| Audio | |
| Audio | Built-in Mic and Speaker |
| Mic Pickup Distance | Up to 8m |
| Speaker Distance | Up to 8m |
| Audio Over Coax | Supported via CVI / TVI |
| Two-Way Talk | Supported via CVI / TVI |
| Audio Interface | Built-in Mic and Speaker |
| Power | |
| Power Supply | 12V DC ±30% |
| Power Consumption | Max. 7.2W, IR On |
| Environment | |
| Operating Temperature | Not specified in the provided specifications |
The Dahua DH-HAC-HDW1200TQP-IL-T is a 2MP HDCVI Eyeball Dome Camera designed to deliver clear Full HD surveillance with advanced dual-light illumination, built-in audio, and flexible video output options. It features a 2MP CMOS image sensor with a maximum resolution of 1920 × 1080, providing detailed video for security monitoring.
The camera uses Multi-Core Light technology with IR and warm light and provides up to 25m IR illumination. Smart IR and warm-light functions allow the camera to adapt its illumination according to the selected mode, including Smart IR & WL, Warm Light Mode, and IR Mode.
The camera supports a fixed-focal M12 lens with 2.8mm and 3.6mm options, both featuring an F2.0 aperture. The 2.8mm lens provides a wider 111.3° horizontal field of view, while the 3.6mm lens provides an 89° horizontal field of view, making the camera suitable for different surveillance coverage requirements.
The camera supports CVI, TVI, AHD, and CVBS signal systems. It provides 1080p resolution at 25fps in PAL and 30fps in NTSC, along with 960H CVBS output. The 1× BNC video output can be switched between supported video formats.
A key feature of this camera is its built-in microphone and speaker. It supports up to 8m microphone pickup and 8m speaker distance, along with audio over coax via CVI/TVI and two-way talk, allowing compatible XVR systems to support interactive audio communication.
The camera includes BLC, HLC, DWDR, and 3D Noise Reduction to help improve image quality in different lighting conditions. It also supports Auto White Balance and Auto/Manual Gain Control for additional image adjustment.
The camera provides 0° to 355° pan range and 15° to 85° tilt range, with support for up to 80 presets. This provides flexible positioning and quick access to preset viewing positions when supported by the connected system.
The camera features a plastic housing and supports wall mounting with an accessory and ceiling mounting. It operates within a wide temperature range of -40°C to +60°C and uses a 12V DC ±30% power supply, with maximum power consumption of 7.2W when IR is on.
2MP HDCVI Eyeball Dome Camera
1920 × 1080 Full HD resolution
2MP CMOS image sensor
Smart IR & Warm Light
Up to 25m IR distance
2.8mm / 3.6mm fixed-focal lens options
F2.0 aperture with M12 lens mount
CVI / TVI / AHD / CVBS support
1× BNC switchable video output
DWDR, BLC, HLC & 3D Noise Reduction
Built-in microphone and speaker
Up to 8m microphone pickup
Up to 8m speaker distance
Two-way talk via CVI / TVI
0°–355° pan and 15°–85° tilt
80 preset positions
12V DC ±30% power supply
Max. 7.2W power consumption
-40°C to +60°C operating temperature
CE-LVD & CE-EMC certified
1-year warranty
