TP-Link VIGI NVR4016H 16-Channel 4K Network Video Recorder NVR

TP-Link VIGI NVR3016H 16-Channel 4K Network Video Recorder (NVR)

The TP-Link VIGI NVR3016H is a professional 16-channel 4K Network Video Recorder (NVR) designed for reliable, high-resolution IP surveillance. It supports up to 16 IP camera channels and recording resolutions of up to 8MP, making it suitable for homes, offices, retail stores, warehouses, factories, educational institutions, and other commercial security installations.

16-Channel 8MP Recording

The VIGI NVR3016H supports up to 16-channel IP camera input and recording resolutions up to 8MP. It supports multiple recording resolutions including 8MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, and QCIF.

With support for H.265+, H.265, H.264+, and H.264 video compression, the NVR efficiently manages video storage and network bandwidth while maintaining clear surveillance footage.

Dual HDMI & VGA Display Output

The NVR features 2× HDMI and 1× VGA video outputs for flexible display configurations. It supports multi-screen layouts of 1, 4, 6, 8, 9, and 16 channels, allowing users to monitor multiple cameras simultaneously.

Advanced Video Detection & Smart Alarms

The TP-Link VIGI NVR3016H includes a wide range of intelligent video detection features such as motion detection, video tampering, scene change detection, line-crossing detection, intrusion detection, region entering/exiting detection, loitering detection, human detection, vehicle detection, abnormal sound detection, and object abandoned/removal detection.

Trigger events include video loss, offline/IP conflict, disk exception, and login exception for improved system monitoring and security.

16-Channel Synchronous Playback

The NVR supports 16-channel synchronous playback, allowing multiple recorded camera feeds to be reviewed simultaneously. Playback functions include play, pause, stop, fast forward, fast backward, frame-by-frame playback, full-screen viewing, video clip, clip export, digital zoom, recording lock, and audio on/off.

Large 4-Bay Storage Capacity

For professional surveillance applications requiring extended recording, the NVR provides 4 SATA interfaces, with support for up to 16TB per HDD. This allows a maximum supported internal storage capacity of up to 64TB when four 16TB HDDs are installed.

It also includes 1× eSATA interface for additional storage connectivity.

High-Speed Network Connectivity

The VIGI NVR3016H features 2× RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces, providing high-speed network connectivity for surveillance data transmission and system management.

It also includes 2× front USB 2.0 ports and 1× rear USB 3.0 port, along with 1-channel RCA audio input and 1-channel RCA audio output.

Two-Way Talk Support

With two-way talk support, compatible surveillance systems can enable audio communication between the monitoring location and connected camera environments, adding convenience for security monitoring and remote communication.

Key Features

• 16-channel IP camera input

• Up to 8MP recording resolution

• 4K video recording support

• 2× HDMI & 1× VGA outputs

• 1/4/6/8/9/16-channel multi-screen display

• H.265+ / H.265 / H.264+ / H.264 compression

• 16-channel synchronous playback

• Manual, scheduled & motion detection recording

• Human & vehicle detection

• Intrusion & line-crossing detection

• Region entering & exiting detection

• Loitering detection

• Object abandoned/removal detection

• Video tampering & scene change detection

• Abnormal sound detection

• Smart frame detection

• Two-way talk support

• 2× Gigabit Ethernet ports

• 2× front USB 2.0 & 1× rear USB 3.0

• 4× SATA interfaces

• Up to 16TB per HDD

• Up to 64TB total internal HDD capacity

• 1× eSATA interface

• 1-channel RCA audio input & output

• 100–240V AC power supply

• 1-year manufacturing warranty

Buy TP-Link VIGI NVR3016H 16-Channel 4K NVR in Bangladesh

The TP-Link VIGI NVR3016H 16-Channel 4K Network Video Recorder is an excellent choice for professional surveillance systems that require multiple camera connections, high-resolution recording, advanced video detection, flexible display options, and large storage capacity.

With 16-channel IP camera support, up to 8MP recording, dual HDMI output, 4 SATA bays, up to 64TB internal storage, Gigabit Ethernet, smart detection, and 16-channel synchronous playback, the VIGI NVR3016H provides a reliable and scalable solution for demanding security installations.

The TP-Link VIGI NVR3016H comes with a 1-year manufacturing warranty.
