4MP 4K PoE IP Camera with 30m IR & White Light
2.8/4mm F1.6 Fixed Lens, 120dB WDR, Smart IR & H.265+
People & Vehicle Analytics, Two-Way Audio, 512GB MicroSD, IP67 & IK10
| Camera | |
| Image Sensor – V1 | 1/2.7” Progressive Scan CMOS |
|---|---|
| Image Sensor – V1.20 | 1/2.65” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified / Scheduled / Auto |
| Lens | |
| Lens Type | Fixed Focal Lens |
| Focal Length | 2.8mm / 4mm |
| Aperture | F1.6 |
| Lens Mount | M12*P 0.5 |
| V1 – 2.8mm FOV | Horizontal 100°, Vertical 54°, Diagonal 118° |
| V1 – 4mm FOV | Horizontal 80.4°, Vertical 41.8°, Diagonal 98.7° |
| V1.20 – 2.8mm FOV | Horizontal 100°, Vertical 54°, Diagonal 118° |
| V1.20 – 4mm FOV | Horizontal 81°, Vertical 43.9°, Diagonal 96.39° |
| DORI – 2.8mm | Detect 64m, Observe 27m, Recognize 13m, Identify 6m |
| DORI – 4mm | Detect 80m, Observe 33m, Recognize 16m, Identify 8m |
| Angle Adjustment | |
| Pan | 0° to 346° |
| Tilt | 0° to 75° |
| Rotation | 0° to 355° |
| Illuminator | |
| Illuminator Type | 2 × IR LED + 2 × White LED |
| IR LED Quantity | 2 |
| IR Range | 30m |
| IR Wavelength | 850nm |
| White LED Quantity | 2 |
| White LED Range | 30m |
| Illuminator Distance | Up to 30m |
| Illuminator Control | Auto / Scheduled / Always On / Always Off |
| Video | |
| Maximum Resolution | 2688 × 1520 |
| Main Stream Resolution | 2688 × 1520, 2560 × 1440, 2304 × 1296, 2048 × 1280, 1920 × 1080, 1280 × 720 |
| Main Stream Frame Rate | Up to 25fps at 50Hz; up to 30fps at 60Hz |
| Sub-Stream Resolution | 848 × 480, 704 × 576, 640 × 480, 640 × 360, 352 × 288, 320 × 240 |
| Sub-Stream Frame Rate | Up to 25fps at 50Hz; up to 30fps at 60Hz |
| 90°/270° Rotation | Frame rate up to 20fps |
| Bit Rate Control | CBR / VBR |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Main Stream Bit Rate | 256Kbps to 6Mbps |
| Sub-Stream Bit Rate | 64Kbps to 512Kbps |
| Image | |
| Image Settings | Mirror, Rotation, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, IR Overexposure Prevention, HLC |
| Image Enhancement | BLC / 3D DNR / HLC / Smart IR |
| Wide Dynamic Range | 120dB |
| WDR Note | When People & Vehicle Analytics is enabled, only DWDR is supported |
| SNR | ≥52dB |
| Image Parameter Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD | Yes |
| Audio | |
| Audio Communication | Two-Way Audio |
| Audio Input | Yes, Built-in Microphone |
| Audio Output | Yes, Built-in Speaker |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64Kbps, G.711 A-law |
| Network | |
| Network Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1X, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| ONVIF | Yes |
| ONVIF Profile | G / S / T |
| Simultaneous Live View | 3 Main Streams + 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Web Browser | Chrome 57+, Firefox 52+, Safari 11+, Microsoft Edge 91+ |
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication |
| Alarm and Event Management | |
| Smart Events | Intrusion Detection, Line-Crossing Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, People Detection, Vehicle Detection, Abnormal Sound Detection, Scene Change Detection |
| Basic Events | Motion Detection with Human & Vehicle Classification, Camera Tampering, Illegal Login |
| Alarm Linkage | Memory Card Video Recording, FTP Upload, Push Notifications, Active Defence Sound Alarm, Active Defence Light Alarm, Email Alarm, Alarm Server |
| Output Notification | Message Push |
| Deep Learning Function | |
The VIGI 4MP Network Camera features a 1/2.7” Progressive Scan CMOS sensor on V1 and a 1/2.65” Progressive Scan CMOS sensor on V1.20, delivering up to 2688 × 1520 resolution for detailed surveillance footage. It supports 2.8mm and 4mm fixed focal lens options with different viewing angles and DORI distances for flexible monitoring.
The camera combines 2 IR LEDs and 2 white LEDs with up to 30m illumination distance, supporting reliable monitoring in low-light conditions. Image enhancement features include 120dB WDR, BLC, 3D DNR, HLC, and Smart IR. It also supports advanced smart events such as intrusion, line crossing, region entry/exit, loitering, people and vehicle detection, abnormal sound detection, and scene change detection.
Two-way audio is supported through the built-in microphone and speaker, with environmental noise filtering and 8KHz audio sampling. People & Vehicle Analytics allows users to search and filter people or vehicles based on different attributes, helping make post-event video searches faster and easier.
For network connectivity, the camera provides a 10/100M Ethernet port with PoE support and ONVIF Profile G/S/T compatibility. It supports MicroSD cards up to 512GB and can be managed through VIGI App, VIGI VMS, VIGI Cloud VMS, Web UI, VIGI Config Tool, and VIGI PC Client. With IP67 waterproof and IK10 vandal-proof protection and a metal body, it is designed for demanding surveillance installations.
