Maxell CR1220 3V Lithium Manganese Dioxide Coin Cell Battery
36mAh Nominal Capacity with 12.5mm Diameter & 2.0mm Height
Non-Rechargeable Battery with -20°C to +85°C Operating Temperature
| Battery | |
| Brand | Maxell |
|---|---|
| Model | CR1220 |
| Battery Type | Coin Cell / Button Cell |
| Chemistry | Lithium Manganese Dioxide |
| Nominal Voltage | 3V |
| Nominal Capacity | 36mAh |
| Nominal Discharge Current | 0.1mA |
| Diameter | 12.5mm |
| Height | 2.0mm |
| Weight | 0.8g |
| Operating Temperature | -20°C to +85°C |
| Rechargeable | No |
| IEC Code | CR1220 |
| Battery Size Code | 1220 |
The Maxell CR1220 is a compact 3V lithium manganese dioxide coin cell battery designed for compatible electronic devices and backup power applications. With a nominal capacity of 36mAh, it provides a practical power source for devices that use CR1220 button cell batteries.
The battery features a 12.5mm diameter and 2.0mm height, with a lightweight design weighing approximately 0.8g. It operates across a temperature range of -20°C to +85°C, making it suitable for compatible devices used in different operating environments.
The Maxell CR1220 is a non-rechargeable battery and follows the CR1220 IEC and battery size code. Its compact coin-cell design makes it suitable for devices requiring a small 3V lithium battery.
