The 2MP Outdoor Pan & Tilt Security Camera is designed to provide reliable surveillance in both indoor and outdoor environments. Featuring a 2MP CMOS image sensor, Full HD 1920 × 1080 resolution, up to 20m IR night vision, and flexible lens options, this camera delivers clear and dependable monitoring in a variety of security applications.
The camera is equipped with a 2MP CMOS image sensor and supports a maximum resolution of 1920 × 1080 pixels, providing clear Full HD video for everyday security monitoring. Its F1.2 maximum aperture and minimum illumination of 0.01 Lux at F1.2 with AGC ON help improve image performance in low-light conditions.
With up to 20 meters of IR distance, the camera provides bright and clear nighttime imaging for outdoor and low-light surveillance. The ICR Day/Night function automatically switches between day and night modes to support continuous monitoring.
The camera is available with 2.8mm or 3.6mm fixed focal lens options, allowing you to choose the appropriate viewing angle according to your surveillance requirements.
2.8mm Lens:
Horizontal FOV: 101°
Vertical FOV: 56°
Diagonal FOV: 118°
3.6mm Lens:
Horizontal FOV: 78°
Vertical FOV: 42°
Diagonal FOV: 92°
Both lens options use an M12 mount.
The camera supports a wide electronic shutter range for different lighting conditions. For PAL, the shutter speed ranges from 1/25s to 1/50,000s, while NTSC supports 1/30s to 1/50,000s.
The camera features a switchable TVI/AHD/CVI/CVBS video interface, allowing it to work with different analog HD CCTV systems. This makes it a practical option for new installations as well as upgrading existing surveillance systems.
Built for demanding environments, the camera operates within a temperature range of -40°C to 60°C and supports humidity levels of 90% or less, non-condensing. It operates using a 12V DC ±25% power supply.
2MP CMOS Image Sensor
1920 × 1080 Full HD Resolution
Up to 20m IR Night Vision
0.01 Lux Minimum Illumination
0 Lux with IR
F1.2 Maximum Aperture
ICR Day/Night
2.8mm / 3.6mm Fixed Focal Lens
M12 Lens Mount
2.8mm: 101° Horizontal FOV
3.6mm: 78° Horizontal FOV
PAL/NTSC Support
Wide Electronic Shutter Speed
**
